Philadelphia, PA

Including many firsts for the United States, such as a gridiron street pattern and open public squares, the city plan of Philadelphia provided a model for city planning that has helped mold the development of cities throughout the country.

The City Plan of Philadelphia is a seminal creation in American city planning in that it was the first American City Plan to provide open public squares for the free enjoyment of the community and a gridiron street pattern featuring streets of varying widths: wide main streets and narrower side streets. In addition this plan was the first city plan in the United States to provide for long-term urban growth. These features inspired the planners of many cities to adopt the Philadelphia Plan as a model.

The City of Philadelphia was founded by William Penn as the Capitol of the Province of Pennsylvania. He determined that the city should be place upon the river for health purposes and easy navigation. Penn also specified that the roads and highways should be laid out first and then the lots for purchase. Thus, ensuring that they be convenient and not encroached on by builders. In the end, Penn directed that the city should extend in length from the Schuykill River to the Delaware River (approximately two miles) and about one mile in width. Thomas Holme was the Surveyor-General of the Province and city planner. He published the engraving of the city plan in London in 1683 to advertise for new emigrants to settle there.

The key features of the Plan were:

  • Gridiron street pattern
  • Central public square for future public building
  • Street widths appropriate to the street's functions
  • Open public squares
  • Foresight to provide ample land for future development within the plan

The last three features listed were firsts in American city planning.

Designing street widths appropriate to their usage was a first for urban planning in the United States. The principle axis streets were one hundred feet wide, streets fronting the river were sixty feet wide, and the remaining streets were fifty feet wide. These dimensions were extravagantly generous in their day and adequately served the city until the advent of the automobile.

The open public squares are the most striking feature of the city plan. While the gridiron street plan had been used in the American colonies as early as 1638 in New Haven, the only public squares provided in earlier colonial plans were for the express use of civic buildings and markets. William Penn specified that the Philadelphia squares, other than the Center Square, were to remain open for the recreation of the residents. The four public squares, situated in each quarter of the original grid pattern, have evolved with the neighborhoods which surround them.

This city plan provided American city planners with a new model for the use of a gridiron street pattern featuring open public squares and varying widths for streets. It also provided city planners with an example of long-range planning and the benefits it can provide.


  1. Corcoran, Irma. Thomas Holme, 1624–1695, Surveyor General of Pennsylvania. Philadelphia, PA: American Philosophical Society, vol. 200, 1992.
  2. Reps, John William. The Making of Urban America; a History of City Planning in the United States. Princeton, NJ: Princeton University Press, 1965.
